Ruijie Reyee RG-ES105GD

The Ruijie Reyee RG-ES105GD is a compact and reliable 5-port Gigabit Ethernet switch designed for small offices, home networks, and business environments. Featuring five 10/100/1000 Mbps RJ45 ports, it delivers high-speed wired connectivity for PCs, printers, IP cameras, and network devices. Its fanless metal housing ensures silent operation and improved durability, while plug-and-play deployment allows for quick and easy installation without configuration. With a 10 Gbps switching capacity, low power consumption, and robust surge and ESD protection, the RG-ES105GD provides stable and efficient network performance for everyday business and home networking needs.

$ 1.00 $ 1.00
Contact Us
Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

Description


CategorySpecificationDetails
ModelModel NumberRG-ES105GD
Product InformationWarranty3 Years
Port SpecificationsTotal RJ45 Ports5


10/100/1000BASE-T Ports5
Power Supply & ConsumptionPower InputDC Adapter


Rated Input Voltage100–240 V AC, 50–60 Hz


Maximum Input Voltage90–264 V AC, 47–63 Hz


Rated Input Current0.3 A


Rated Output Voltage5 V DC


Maximum Output Current1 A


Maximum Power Consumption5 W


Power Supply TypeDC Power Adapter
System SpecificationsFlash Memory1 MB


Forwarding Rate7.44 Mpps


Switching Capacity10 Gbps
Dimensions & WeightCasingMetal


Product Dimensions (W × D × H)119 × 75 × 24 mm (4.69 × 2.95 × 0.94 in.)
Hardware SpecificationsWeight250 g (0.55 lbs) without packaging


Shipping Weight0.47 kg (1.04 lbs)
Environment & ReliabilityFanFanless Design


CoolingNatural Cooling


Acoustic NoiseNone


Mounting OptionsDesk


Hot Swapping of CablesSupported by service port and power connector


MTBF200,000 Hours


Operating Temperature0°C to 40°C (32°F to 104°F)


Storage Temperature-40°C to +70°C (-40°F to +158°F)


Operating Humidity10% RH to 90% RH (non-condensing)


Storage Humidity5% RH to 95% RH (non-condensing)


Operating Altitude-500 m to +5,000 m (-1,640.42 ft to +16,404.20 ft)


Storage Altitude-500 m to +5,000 m (-1,640.42 ft to +16,404.20 ft)
ProtectionESD Protection (Air Discharge)8 kV


ESD Protection (Contact Discharge)6 kV


Surge Protection – Service Port±4 kV (Common Mode)


Surge Protection – Power Connector±2 kV (Common Mode), ±1 kV (Differential Mode)
